Arctic F14 W&B

F14

140 mm Standard Case Fan

LONG SERVICE LIFE

The Fluid Dynamic Bearing comes with an oil capsule that avoids lubricant leakage. Thus this bearing is as quiet as a sleeve bearing but comes with a significantly higher service life.

INNOVATIVE DESIGN ENABLES QUIET AND EFFICIENT VENTILATION

The innovative design of the fan blades improves the air flow and facilitates a highly efficient ventilation. The impeller was designed with a focus on minimzing the noise level yet delivering the desired airflow and pressure.

TECHNICAL SPECIFICATIONS & MANUAL

General data
Performance
Fan Speed:    1350 rpm
Airflow:    74 CFM/ 126 m³/h
Static Pressure:    1,3 (mm/H2O)
Noise Level:    0.5 Sone
Fan
Fan Frame:    Standard
Controll Typ:    Fixed Speed
Connector:    3-Pin Connector
Fan Bearing:    Fluid Dynamic Bearing
Electric Characteristics:
Typical Voltage:    12 V DC
Starting Voltage:    6 V
Current:    0.20 A
Cable Lenght:    400 mm
Size & Weight
Lenght:    140 mm
Width:    140 mm
Height:    27 mm
Weight:    180 g

ssee more details at  arctic.de
