Mesh & Transparent Front Panel
Dual 200mm ARGB Fans
ARGB Lighting System
Tempered Glass Side Panel
Case Handle:
PERFORMANCE COMES IN PAIRS
Two front panels, two 200mm ARGB fans, and a handle to grip onto when the adrenaline kicks in. The MasterCase H500 is established as the go-to chassis for high performance airflow. Now, with 200mm ARGB fans, its legacy is upgraded with premium lighting.
MESH & TRANSPARENT PANELS INCLUDED
Each choice of front panels decide whether the build will excel at ruthless airflow performance or head-turning aesthetics. Of course, the mesh is the ideal choice for providing the pre-installed fans with high volumes of fresh air. The transparent panel, on the other hand, parades those fans in crystal clear view.
DUAL 200MM ARGB FANS
The iconic, addressable RGB fans are the core of the H-Series in design and function, capable of operating quietly while moving high volumes of air due to their size.
ARGB LIGHTING SYSTEM
The pre-installed ARGB fans can be managed by either the motherboard or an included controller to create a comprehensive ARGB lighting system.
TEMPERED GLASS SIDE PANEL
Gaming hardware, cooling components, and the pure pride of the builder is shown in panoramic view through an edge-to-edge tempered glass side panel.
Specifications:
| Model Number |
MCM-H500-IGNN-S01 |
|
|
|
|
|
|
|
| Materials |
Steel, Plastic, Mesh |
|
| Dimensions (L x W x H) |
525 x 228 x 502mm (Incl. Panels) |
|
| Motherboard Support |
Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12″ x 14.1″, may impact cable management features) |
|
|
|
|
|
| 2.5″ / 3.5″ Drive Bays (combo) |
2 |
|
|
|
| I/O Panel |
2 x USB 3.2 Gen 1 (USB 3.0), 2x USB 2.0, 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB/PWM Hub (may depend on region and model) |
|
| Pre-installed Fans – Front |
2x 200mm ARGB Fan |
|
| Pre-installed Fans – Rear |
1x 120mm (Black) |
|
| Fan Support – Top |
2x 120mm, 2x 140mm, 1x 200mm |
|
| Fan Support – Front |
3x 120mm, 2x 140mm, 2x 200mm |
|
| Fan Support – Rear |
1x 120mm |
|
| Radiator Support – Top |
120mm, 140mm, 240mm |
|
| Radiator Support – Front |
120mm, 140mm, 200mm, 240mm, 280mm, 360mm |
|
| Radiator Support – Rear |
120mm |
|
| Clearance – CPU Cooler |
167mm/6.5″ |
|
| Clearance – PSU |
180mm/7.1″ |
|
| Clearance – GFX |
410mm/16.1″ |
|
| Dust Filters |
Top, Front, Bottom |
|
| Power Supply Support |
Bottom Mount, ATX |
|
