Interchangeable Front Panels
Addressable RGB Fans & Controller
Four Tempered Glass Panels
Adjustable Graphics Card Support Arm
Watercooling Support
Covers for Clean Building
Rich Connectivity

specifications

MODEL NUMBER
MCM-H500M-IHNN-S00
AVAILABLE COLOR(S)
Iron Grey
MATERIALS – OUTLOOK
Steel Mesh, Glass
MATERIALS – BODY
Steel
MATERIALS – SIDE PANEL
Tempered Glass
DIMENSIONS (L X W X H)
544 x 248 x 546mm / 21.4 x 9.8 x 21.5 inch
MOTHERBOARD SUPPORT
Mini ITX, Micro ATX, ATX, E-ATX
EXPANSION SLOTS
7+2
5.25″ DRIVE BAYS
0
2.5″ / 3.5″ DRIVE BAYS (COMBO)
2
DRIVE BAYS 2.5″ SSD
6
I/O PANEL
1x USB 3.1 Type-C, 4x USB 3.0 Type-A, Audio In & Out (supports HD audio)
PRE-INSTALLED FANS – FRONT
2x 200mm ARGB Fan (Speed: 800RPM / Connector: 3Pin + ARGB 3pin)
PRE-INSTALLED FANS – REAR
1x 140mm fan (Speed: 1200RPM / Connector: 3Pin)
FAN SUPPORT – TOP
3x 120mm, 2x 140/200mm
FAN SUPPORT – FRONT
3x 120/140mm, 2x 200mm Fan
FAN SUPPORT – REAR
1x 120/140mm
RADIATOR SUPPORT – TOP
120mm, 140mm, 240mm, 280mm, 360mm
RADIATOR SUPPORT – FRONT
120mm, 140mm, 240mm, 280mm, 360mm
RADIATOR SUPPORT – REAR
120mm, 140mm
CLEARANCE – CPU COOLER
190mm
CLEARANCE – GFX
412mm
CLEARANCE – PSU
200mm
POWER SUPPLY SUPPORT
Bottom mount, ATX PS2
EAN CODE
4719512072165
UPC CODE
884102044663
SERIES
MasterCase Series
SIZE
Mid Tower
