HS420 VGPU Edition Black Mid Tower Case -white

Mid Tower

SGCC sheet metal, tempered glass, ABS, Nylon, Silicon, Zinc alloy, NdFeB magnets

541 x 259.5 x 547 mm

19 kg

1 year

USB 3.2 Gen 2 Type-C x1

USB 3.2 Gen 1 Type-A x2

Audio Jack x1

Power & Reset Button x1

E-ATX (Max Width 277 mm) / ATX / M-ATX / Mini-ITX

6 horizontal, 4 vertical

Maximum Amount: 11

Top: 3 x 120 / 3 x 140 mm

Right: 3 x 120 / 3 x 140 mm

Bottom: 3 x 140 mm

Rear: 2 x 120 / 2 x 140 mm (Thickness Up to 30 mm)

Fan Ports: 2 x PWM repeaters, 12 ports total

Location: 1 x Cable Management Tray
1 x PSU Shroud

Fan Connectors: 6 ports per repeater x 4-pin PWM

(Connect your primary fan to the white port to control PWM signal.
All other ports mirror the white port’s signal.)

Fan Rated Voltage: 12V

Fan Safety Current: Up to 2.6A across 6 ports

Power Connector: 1 x SATA Power

Power Safety Current: 1 x SATA connector power input, 12V → 2.6A (max)

Height: Up to 185 mm. Tower cooler size depends on GPU width. CPU center to graphics card PCIe edge connector; ~199mm (varies by motherboard). Liquid cooling recommended.

Top: 280 / 360 / 420 mm (Thickness: 65 mm, not overlapping with RAM)

Right: 280 / 360 / 420 mm (Thickness: 80 mm w/ GPU >317mm, 80 mm w/ top AIO)

Width: Up to 145 mm

Length: Up to 470 mm

Width: Up to 195 mm. GPU width support depends on CPU cooler size. CPU center to graphics card PCIe edge connector: ~199mm (varies by motherboard). Liquid cooling recommended.

4 Slots

PCI Express 5.0 Riser Cable Included

If the fan and radiator thickness is greater than 65 mm: 420 mm – 32 mm / 360 mm – 43 mm

ATX

Length: Up to 220mm (Clearance – 290mm)

Right Fan Mount: 4 Storage Bays: 4 x 3.5” / 8 x 2.5”

Cable Management Tray: 1 Storage Bay: 1 x 3.5” / 2 x 2.5”

Storage Bay Included: 4x

VESA Mounting: 75 x 75 mm / 100 x 100 mm

Display Size: 14 in. (Max)

Location: Front Right Pillar

Bottom: 1 (Removable)

Top: 1 (Built-in)

Right: 1 (Built-in)

Rear Bottom: 1 (Removable)
