Processor Number <button type=”button” class=”btn btn-tooltip-trigger view-modal info-modal” data-toggle=”modal” data-target=”.upe-modal” data-title=”Processor Number” data-description=”The Intel processor number is just one of several factors—along with processor brand, system configurations, and system-level benchmarks—to be considered when choosing the right processor for your computing needs. Read more about interpreting Intel® processor numbers or Intel® processor numbers for the Data Center.” data-search-title=”Find products with Processor Number” data-search-href=”” data-search-icon=”true” data-keyboard=”true” aria-label=”Processor Number” style=”font-size: 1rem; line-height: 1; font-weight: 700; vertical-align: initial; border-width: 0px; border-style: initial; border-color: initial; white-space: normal; padding: 0px; border-radius: 0px; position: relative; min-width: 1rem; height: auto; outline: 0px; width: auto; box-shadow: none;”>
i5-13600K
Status
Launched
Launch Date
Q4’22
Lithography
Intel 7
Recommended Customer Price
$319.00 – $329.00
Use Conditions <button type=”button” class=”btn btn-tooltip-trigger view-modal info-modal” data-toggle=”modal” data-target=”.upe-modal” data-title=”Use Conditions” data-description=”Use conditions are the environmental and operating conditions derived from the context of system use.
For SKU specific use condition information, see PRQ report.
For current use condition information, see Intel UC (CNDA site)*.” data-search-title=”Find products with Use Conditions” data-search-href=”” data-search-icon=”true” data-keyboard=”true” aria-label=”Use Conditions” style=”font-size: 1rem; line-height: 1; font-weight: 700; vertical-align: initial; border-width: 0px; border-style: initial; border-color: initial; white-space: normal; padding: 0px; border-radius: 0px; position: relative; min-width: 1rem; height: auto; outline: 0px; width: auto; box-shadow: none;”>
PC/Client/Tablet
CPU Specifications
Total Cores
14
# of Performance-cores
6
# of Efficient-cores
8
Total Threads
20
Max Turbo Frequency
5.10 GHz
Performance-core Max Turbo Frequency
5.10 GHz
Efficient-core Max Turbo Frequency
3.90 GHz
Performance-core Base Frequency
3.50 GHz
Efficient-core Base Frequency
2.60 GHz
Cache
24 MB Intel® Smart Cache
Total L2 Cache
20 MB
Processor Base Power
125 W
Maximum Turbo Power
181 W
Supplemental Information
Embedded Options Available
No
Memory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels
2
Max Memory Bandwidth
89.6 GB/s
ECC Memory Supported ‡ <button type=”button” class=”btn btn-tooltip-trigger view-modal info-modal” data-toggle=”modal” data-target=”.upe-modal” data-title=”ECC Memory Supported ‡” data-description=”ECC Memory Supported indicates processor support for Error-Correcting Code memory. ECC memory is a type of system memory that can detect and correct common kinds of internal data corruption. Note that ECC memory support requires both processor and chipset support.” data-search-title=”Find products with ECC Memory Supported ‡” data-search-href=”/content/www/us/en/ark/search/featurefilter.html?productType=873&0_ECCMemory=True” data-search-icon=”true” data-keyboard=”true” aria-label=”ECC Memory Supported ‡” style=”font-size: 1rem; line-height: 1; font-weight: 700; vertical-align: initial; border-width: 0px; border-style: initial; border-color: initial; white-space: normal; padding: 0px; border-radius: 0px; position: relative; min-width: 1rem; height: auto; outline: 0px; width: auto; box-shadow: none;”>
Yes
Processor Graphics
Processor Graphics ‡ <button type=”button” class=”btn btn-tooltip-trigger view-modal info-modal” data-toggle=”modal” data-target=”.upe-modal” data-title=”Processor Graphics ‡” data-description=”Processor Graphics indicates graphics processing circuitry integrated into the processor, providing the graphics, compute, media, and display capabilities. Processor graphics brands include Intel® Iris® Xe Graphics, Intel® UHD Graphics, Intel® HD Graphics, Iris® Graphics, Iris® Plus Graphics, and Iris® Pro Graphics. See the Intel® Graphics Technology for more information.
Intel® Iris® Xe Graphics only: to use the Intel® Iris® Xe brand, the system must be populated with 128-bit (dual channel) memory. Otherwise, use the Intel® UHD brand.” data-search-title=”Find products with Processor Graphics ‡” data-search-href=”” data-search-icon=”true” data-keyboard=”true” aria-label=”Processor Graphics ‡” style=”font-size: 1rem; line-height: 1; font-weight: 700; vertical-align: initial; border-width: 0px; border-style: initial; border-color: initial; white-space: normal; padding: 0px; border-radius: 0px; position: relative; min-width: 1rem; height: auto; outline: 0px; width: auto; box-shadow: none;”>
Intel® UHD Graphics 770
Graphics Base Frequency
300 MHz
Graphics Max Dynamic Frequency
1.50 GHz
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units
32
Max Resolution (HDMI)‡ <button type=”button” class=”btn btn-tooltip-trigger view-modal info-modal” data-toggle=”modal” data-target=”.upe-modal” data-title=”Max Resolution (HDMI)‡” data-description=”Max Resolution (HDMI) is the maximum resolution supported by the processor via the HDMI interface (24bits per pixel & 60Hz). System or device display resolution is dependent on multiple system design factors; actual resolution may be lower on your system.” data-search-title=”Find products with Max Resolution (HDMI)‡” data-search-href=”” data-search-icon=”true” data-keyboard=”true” aria-label=”Max Resolution (HDMI)‡” style=”font-size: 1rem; line-height: 1; font-weight: 700; vertical-align: initial; border-width: 0px; border-style: initial; border-color: initial; white-space: normal; padding: 0px; border-radius: 0px; position: relative; min-width: 1rem; height: auto; outline: 0px; width: auto; box-shadow: none;”>
